High Yield Nylon Woven Filter Fabric Mesh PA-22GG-950UM Thread Diameter 300UM

Name: High Yield Nylon Woven Filter Fabric Mesh PA22GG950UM Thread Diameter 300UM
Brand: SHARE
Price: 1 USD

Buy cheap High Yield Nylon Woven Filter Fabric Mesh PA-22GG-950UM Thread Diameter 300UM product

Brand Name : SHARE

Model Number : 22GG

Certification : SGS

Place of Origin : CHINA

MOQ : 100meters

Payment Terms : L/C, T/T, Western Union,

Delivery Time : 5-7days

Packaging Details : Carton

Material : Polyamide

Mesh Count : 12GG-74GG

Weave : Plain Woven 1:1

Width : 130cm, 145cm

Yarn Type : Mono-filament

Color : White

Mesh Opening : 950um

Application : GG Flour Milling

Filtration : Coarse Filtration

name : Nylon Woven Filter Fabric

Contact Now

PA-22GG-950 Polyamide Flour Sifting and Milling Mesh

SHARE POLYAMIDE FLOUR MILLING MESH-PA-22GG-950UM

PA-22GG-950um

Mesh Count: 20tpi (threads per inch)
Thread Diameter: 300um
Mesh Opening: 950um
Width: 130cm

1. Characteristics/advantages of Flour Mesh offered by SHARE

High throughput
High yield
Long service life
High reliability
Wide product range

2. Main applications:

Food processing screening filter,
Plansifter in flour milling,
Single and double bin flat screen,
Aluminium alloy screen,
Vibration screen,
Sieve bone,
Press filter cloth,
Starch filter cloth, etc

4. Datasheet:

Fabric No.	Mest Count		Thread Diameter (um)	Mesh Opening (um)	Open Area (%)	Weight(gsm)	Width
	n/cm	n/inch					inch	40	54	57
	n/cm	n/inch					cm		136
PA-10GG	3.94	10	550	1990	61	237			●
PA-12GG	4.33	11	400	1820	67	153			●
PA-14GG	5.11	13	400	1600	64	170			●
PA-16GG	5.90	15	350	1317	62	156			●
PA-18GG	6.69	17	350	1180	59	170			●
PA-20GG	7.48	19	300	1023	60	144			●
PA-22GG	7.87	20	300	950	58	153			●
PA-24GG	8.66	22	300	850	56	163			●
PA-26GG	9.05	23	300	800	54	172			●
PA-28GG	10.62	27	250	705	54	140			●
PA-30GG	11.02	28	250	659	53	146			●
PA-32GG	11.41	29	250	610	51	153			●
PA-34GG	11.81	30	250	570	49	159			●
PA-36GG	12.59	32	250	530	47	166			●
PA-38GG	14.17	36	200	500	52	119			●
PA-40GG	14.56	37	200	486	50	123			●
PA-42GG	14.96	38	200	466	49	128			●
PA-44GG	16.14	41	200	425	46	136			●
PA-46GG	16.92	43	200	388	44	145			●
PA-48GG	17.71	45	200	364	42	148			●
PA-50GG	18.11	46	200	355	41	153			●
PA-52GG	20.47	52	150	338	48	98			●
PA-54GG	21.65	55	150	315	46	103			●
PA-58GG	22.04	56	150	300	44	105			●
PA-60GG	22.83	58	150	285	43	110			●
PA-62GG	23.62	60	150	273	42	112			●
PA-64GG	24.01	61	150	266	41	115			●
PA-66GG	28.34	72	100	252	51	61			●
PA-68GG	29.13	74	100	243	50	63			●
PA-70GG	29.52	75	100	238	48	64			●
PA-72GG	30.31	77	100	229	47	66			●
PA-74GG	31.88	81	100	213	46	69			●

5. Packing

High Yield Nylon Woven Filter Fabric Mesh PA-22GG-950UM Thread Diameter 300UM
